Capacity
Up To 500 BPM
Bag Width
25-280mm
Bag Height
35-110mm
Bag Length
30-1000mm
Pillow type packing for different products
Whole automatic packing Line can be designed to connect to your producing line
Max speed 1600 pcs/min for candy packing
| Bag Length Range | 150-450mm | Max Speed | 50-190 bags/min |
| Bag Width Range | 25-110mm | Power Supply | 220V 50-60Hz |
| Bag Height Range | < 50mm | Total power | 3kw |
| Max. Dia of Film | Ø350mm | Machine Weight | 750kg |
| Bag Length Range | 170-400mm | Max Speed | 30-140 bags/min |
| Bag Width Range | 35-100mm | Power Supply | 220V 50Hz |
| Bag Height Range | < 60mm | Total power | 3kw |
| Max. Dia of Film | Ø350mm | Machine Weight | 900kg |
| Bag Length Range | 170-400mm | Max Speed | 30-140 bags/min |
| Bag Width Range | 35-100mm | Power Supply | 220V 50Hz |
| Bag Height Range | < 60mm | Total power | 3kw |
| Max. Dia of Film | Ø350mm | Machine Weight | 900kg |
| Bag Length Range | 240-600mm | Max Speed | 10-45 bags/min |
| Bag Width Range | 80-200mm | Power Supply | 220v 50-60HZ |
| Bag Height Range | < 110mm | Total power | 3.3Kw |
| Max. Dia of Film | Ф300mm | Machine Weight | 900kg |
| Bag Length Range | 180~400mm | Max Speed | 15-80 bags/min |
| Bag Width Range | 125~250mm | Power Supply | 220V 50Hz |
| Bag Height Range | 10~60mm | Total power | 4Kw |
| Max. Dia of Film | Ø350mm | Machine Weight | 950KG |
| Bag Length Range | 180~400mm | Max Speed | 80bag/min |
| Bag Width Range | 125~280mm | Max Width of Film | 630mm |
| Bag Height Range | 10~90mm | Max. Dia of Film | Ø350mm |
| Bag Length Range | 20-40/40-80/80-160 mm | Max Speed | 500/min |
| Bag Width Range | 12-20 (Ф8-13) mm | Power Supply | 220V 50Hz |
| Bag Height Range | 3-18mm | Total power | 4.6Kw |
| Overall Dimension | 2250*900*1550mm | Machine Weight | 1250kg |
| Bag Length Range | 12-40mm | Max Speed | 1200 bags/min |
| Bag Width Range | 12-30mm | Power Supply | 220V 50Hz |
| Bag Height Range | 5-18mm | Total power | 4Kw |
| Finished Bag Length | 50-80mm | Machine Weight | 1400kg |
| Bag Length Range | 12-50mm | Production Capacity | 1400bags/min |
| Bag Width Range | 12-30mm | Power Supply | 380v 50HZ 3P/AC |
| Bag Height Range | 5-18mm | Total power | 6kw |
| Finished Bag Length | 50-120mm | Machine Weight | 1500kg |
The Horizontal Flow Wrapper is the ultimate solution for pillow-type packing of bulk products, seamlessly integrating into your production line for full automation. Designed to meet the needs of various industries, including food, pharmaceuticals, and cosmetics, this machine offers high-speed capabilities, packing up to 1,600 pieces per minute, making it an efficient choice for large-volume production. Discover how the Horizontal Flow Wrapper can enhance your packaging efficiency today!
* Key Features
1. Pillow-Type Packing Design: Our Horizontal Flow Wrapper ensures optimal protection for products during the packing process. This design is particularly suitable for items requiring a high level of hygiene, making it ideal for food and pharmaceutical applications.
2. Precision and Consistency: With advanced technology, our machine packs products with remarkable precision, reducing waste and enhancing productivity.
3. Easy Integration: The Horizontal Flow Wrapper is designed for seamless integration into your existing production line. We can customize a fully automated packing line that connects effortlessly to streamline your operations and maximize efficiency, minimizing disruptions.
4. Commitment to Quality：Our company is dedicated to delivering high-quality products and services. The Horizontal Flow Wrapper is constructed from premium materials and components, ensuring consistent and reliable performance while reducing downtime and maintenance costs.
